Constant Current LED driver 230Vinput 650–1050mA CC

Name: Tridonic Constant Current LED driver 230Vinput 650–1050mA CC
Brand: Tridonic
Price: 33.34 EUR
Availability: OutOfStock
Rating: 0 (0 reviews)

0 Review(s)

€33,34 Excl. tax €66,68 Excl. tax
€40,34 Incl. tax €80,68 Incl. tax. Out of stock, but available

Unit price: €33,34 / Piece

Compact LED driver for Constant Current (650-1050 mA) with NFC and DALI. Dimming 1-100%, max. 38 W, efficiency up to 88%, standby < 0.4 W, lifetime up to 100,000 h. Suitable for class I & II luminaires, with thermal protection and programmable output curr Read more

Specifications

Brand:

Tridonic

Housing:

Surface-mounted housing

Input voltage:

230Vac

DALI Type:

DT6

DALI-2 certified:

Yes

Article number:

28004043

EAN:

9006210778921

Availability:

Out of stock, but available

Delivery time:

Will be shipped within approximately 8 working days.

Information

Datasheet

LC 38/650-1050/42 o4a NF SC EXC3 Art. No. 28004043

Compact LED Driver for Constant Current

This compact LED driver provides a constant current of 650-1050 mA and supports NFC and DALI configuration. With a dimming range of 1-100% and a maximum output power of 38 W, this driver offers high efficiency of up to 88% with an extremely low standby power consumption of < 0.4 W.

Key Features:

Constant Current: 650-1050 mA
Dimming range from 1-100% (min. 5 mA)
Maximum output power: 38 W
Efficiency up to 88%
Thermal protection according to EN 61347-2-13 C5e
Suitable for luminaires of protection class I and II
Nominal lifetime up to 100,000 hours
In-field programming via NFC
IP20 protection

Technical Specifications

Nominal voltage	220 – 240 V
AC voltage	198 – 264 V
DC voltage	176 – 280 V
Maximum output voltage	60 V
Protection class	IP20
Dimensions (LxWxH)	97 x 43 x 30 mm
Lifetime	Up to 100,000 hours
Warranty	5 years
