PWM-120-12DA2 120W 12V Constant Voltage (CV)
Specifications
Information
PWM-120-12DA2 Driver LED
The PWM-120-12DA2 LED driver from Mean Well is a high-quality AC-DC driver with a Constant Voltage (CV) output. This driver provides an output voltage of 12V and a current of 10A, with a power of 120W, making it ideal for LED strips. The device supports dimming technology with DALI 2.0 and has an IP67 housing, making it suitable for use in demanding environments.
Main Features
- Output Voltage: 12V
- Output Current: 10A
- Power: 120W
- Input Voltage: 90 - 305V
- IP67 water- and dustproof
- Dimming Technology: DALI 2.0
- Enclosed Plastic housing
- Dimensions: 191 x 63 x 37.5 mm
- Net weight: 970 grams
Available Types
- PWM-60-24DA2: 60W 24V Constant Voltage (CV)
- PWM-120-24DA2: 120W 24V Constant Voltage (CV)
- PWM-90-12DA2: 90W 12V Constant Voltage (CV)
- PWM-90-24DA2: 90W 24V Constant Voltage (CV)
- PWM-90-48DA2: 90W 48V Constant Voltage (CV)
- PWM-120-12DA2: 120W 12V Constant Voltage (CV)
The Mean Well PWM-120-12DA2 is perfect for applications that require reliable and efficient LED lighting. With a wide input range and robust construction, it is an excellent choice for both indoor and outdoor use.
