LCM-40DA2 LED driver 42 W 1.05 A 2 - 100 V Constant Current (CC)
Specifications
Information
Datasheet
LCM-40DA2 LED Driver 40 W
The LCM-40DA2 LED driver is a versatile AC-DC driver with constant current (CC), ideal for various LED lighting applications. This driver offers modular outputs from 0.35A to 1.05A and supports both DALI 2.0 and push dimming, allowing easy adjustment of lighting as needed.
Key specifications:
- Output power: 40 W
- Output voltage: 40V, 45V, 57V, 67V, 80V, 100V
- Output current: 0.35A, 0.5A, 0.6A, 0.7A, 0.9A, 1.05A
- Input voltage: 180-295V
- Dimmable: DALI 2.0 and push
- Extra output: 12Vdc at 50mA
- Protection rating: IP20
- Dimensions: 81.5 x 23 x 123.5 mm
- Weight: 240 grams
- RoHS compliant
The LCM series also offers other models such as the LCM-25DA2 LED driver 25 W and the LCM-60DA2 LED driver 60 W, each with their own specific applications and benefits. All models in this series feature an enclosed plastic housing for added durability and safety.
