DALI RM16 DE WE
The DALI RM16 DE WE relay controls 230V AC loads up to 2kW via DALI. Features inrush current limitation and configurable behavior on bus failure. Ideal for high inrush currents. Read more
Specifications
Brand:
Lunatone
Housing:
Remote housing
DALI-2 certified:
No
Article number:
86458629-DE-WE
EAN:
9010342011191
Availability:
In stock (8)
Delivery time:
Will be shipped within 1 to 2 working days.
Information
DALI RM16 DE WE
The DALI RM16 DE WE relay offers an efficient and reliable solution for switching 230V AC loads up to 2kW via the DALI bus. This relay is equipped with an integrated inrush current limiter, making it ideal for applications with high inrush currents. The relay's behavior in the event of a bus failure can be easily configured via the DALI Cockpit configuration tool.
Main Features
- Switches 230V AC loads up to 2kW
- Integrated inrush current limitation (up to 100A)
- Configurable behavior on bus failure (on/off/no change)
- Suitable for high inrush currents
- Compatible with DALI-2 (Device Type 7)
- Compact design, easy installation
Technical Specifications
| Power Supply | Via DALI bus |
|---|---|
| Current Consumption | 2.7 mA |
| Switching Voltage | 250Vac |
| Max. Rated Load | 2000VA |
| Circuit Protection | 12A max |
| Max. Inrush Current | Limited to 100A |
| Max. Continuous Current | 16A |
| Relay Contact | 1 NO |
| Switching Cycles at Rated Load | More than 50,000 |
| Protection Class | II |
| Protection Rating | IP40 (housing), IP20 (terminals) |
| Dimensions | 120mm x 30mm x 22mm |
| Operating Temperature | -20°C to 60°C |
Related Types
- RM16 DE: Art. Nr.: 86458629-DE
- RM16 CEL: Art. Nr.: 86458629-CEL
- RM16 HS: Art. Nr.: 86456203-HS, 86458629-HS
